Trijicon - Thermal Riflescope Reap-IR 24mm BLK (2021-2024 Model)

$5,639.99

Notify me when back in stock

Overview

Overview

The REAP-IR® mini thermal riflescope is a small, rugged, and powerful thermal riflescope that lets you engage targets in any light. The heart of the system is a state-of-the art 640x480, 12 micron thermal image sensor that provides superior image quality in any lighting condition.  Redesigned electronic hardware and a new digital thumbstick improve system response and enable the use of external USB power sources and digital video recorders.  It's also built to last - in the USA.



Specifications

Length x Width x Height
  • 8.4 in x 3.1 in x 2.9 in
  • (213.36mm x 78.74mm x 73.66mm)
Weight
  • 24.7 oz. (700.23g)
Magnification
  • 1.2x
Objective Size
  • 24mm
Power Source
  • CR 123 or External USB
Battery Life
  • 2 hours per CR 123
Eye Relief
  • 1.063 in. (27mm)
Field of View (degrees)
  • 18 degrees Horizontal°
Mount
  • QLOC
Diopter Range
  • -6 / +2
Housing Material
  • Aluminum
Submersion Depth
  • 3.28 ft. (1m)
Operating Temperature
  • -25.6F to 122F (-32c to 50c)
Sensor Type
  • VOx
Digital Zoom
  • 8X
Sensor Resolution
  • 640x480
Sensor Pixel Pitch
  • 12 µm
Focal Length
  • 24 mm
Frame Rate
  • 30 Hz / 60 Hz
Video Output
  • RS-170



Downloads
